OverviewTowers2Floors12Units369Total Project Area3.8 acres (15.4K sq.m.)STRUCTURE

• R.C.C framed structure with earth quake resistance design

SUPERSTRUCTURE

• Solid CC blocks with 200mm thick external and 100mm thick internal walls

PLASTERING

• Single coat cement plastering with sponge finish on all internal walls and ceiling • Double coat cement plastering with sponge finish for external walls

FLOORING

• Flat interior flooring with GVT finish of size 600mm × 1200mm in hall/kitchen/dining/foyer • 600mm × 1200mm GVT in all bedrooms • Balconies: Anti-skid tiles 600×600mm • External staircases: Granite flooring • Corridors & Semi-Veranda: 600mm × 1200mm vitrified tiles • Service staircases and lift lobbies: Kota stone flooring • Main entrance lobbies: GVT 1200mm × 1800mm premium tiles

SKIRTING

• 100mm skirting of same as the flooring

TOILETS

• 600mm × 600mm anti-skid ceramic flooring • Tile dado up to lintel level (600mm × 600mm ceramic tiles)

UTILITY

• Anti-skid ceramic flooring • Tile dado up to sill level

KITCHEN

• Provision for water purifier, chimney, and hob • Modular kitchen provision

RAILING

• SS railing for external staircases up to the first two floors; MS railing thereafter • MS railing for balconies, service staircases, and lobbies

ELECTRICAL

• Concealed copper wiring (Polycab, Finolex, RR Cable, or equivalent) • Switches: Legrand, Schneider, Hafele, Salzer, Anchor, or equivalent • MCB: Schneider, Legrand, or equivalent

LIFTS

• 6 passenger lifts and 1 service lift • Make: Johnson or equivalent

PAINTING

• Internal Walls: Double coat putty with two coats of premium emulsion paint (Asian Paints or equivalent) • External Walls: Texture finish with two coats of exterior emulsion paint (Asian Paints or equivalent)

WINDOWS

• All windows, French windows, and French doors in UPVC (VEKA or equivalent)

DOORS

• Main door: Size 4’×8’, class-1 wooden frame and shutters with architrave • Bedroom doors: 3’3”×8’, frame with African Teak solid frame, flush shutter with both side laminates • Toilet & utility doors: 2’6”×7’, frame with African Teak solid frame & WPC shutters with laminated finish

GRILLS

• M.S grills for only ground floor

SANITARY

• CP fittings: Grohe American standard • Sanitary fittings: Grohe American standard

PARKING AREA

• VDF in basement car parks

PROVISIONS

• AC provision in all bedrooms and living hall • Exhaust fan provision in all toilets and kitchen

WATER SUPPLY

• Municipal water supply will be availed and supplied for all potable uses • Borewell water softened and supplied • STP water reused as per statutory requirements • Rainwater harvesting pits for ground water enhancement • Roof water harvested for domestic use

ENERGY UTILITY

• HT supply for the project with a prepaid metering system • 3-phase power supply to each flat with 100% DG backup • Energy-efficient lifts and lighting in all areas of the project

ICT

• FTTH connection to each flat • Intercom system with EPABX network • Networked DTH system

SAFETY & SECURITY

• CCTV cameras in common areas to monitor entry and exits • Provision for CCTV extension on typical floors • Boom barriers with smart cameras for vehicular access

FIRE SECURITY

• Fire sprinklers for entire basement car park area • Fire hydrant system as per norms • FAPA system as per norms
